PCB Design and PCB Layout From Concept to Production

We provide complete PCB design and layout solutions, converting your concepts into reliable, high performance circuit boards. With 20+ years of experience and 500+ projects completed, we deliver defect-free designs for industrial controls, automotive systems, medical devices, 5G & RF modules, and IoT technologies.

Why Partner with Us?

1. Expert Design

Tailored Analysis: Custom layer stack-ups (1-32 layers) and materials selected for signal integrity (≥10GHz), thermal performance, and budget.

Rigorous Testing: Signal integrity (SI), power integrity (PI), and EMI/EMC validation using Cadence Allegro and Mentor Xpedition, addressing 90% of design risks early.

Manufacturing Focused Design: IPC-610 compliance to minimize production defects by 30-50%.

2. Optimized Layout Solutions

High-Density Interconnects: 0.1mm micro-vias, 3/3μm trace/spacing for compact 5G and wearable devices.

Heat Management: Custom copper thickness (1-10oz) and thermal via arrays to reduce hotspots by 40%.

EMC Assurance: Shielded layers, ±5% impedance control, and grounding strategies for FCC/CE compliance.

3. Full-Cycle Support

Fast Turnaround: Initial design draft in 48 hours.

Cost Efficient BOM: Component lifecycle management to reduce procurement costs by 15-30%.

Production-Ready Output: Gerber files, assembly drawings, 3D models, and clear manufacturing guidelines.

Clear Process

Requirement Review → 2. Schematic Design & Testing → 3. Layout & Routing → 4. DFM/DFA Checks → 5. File Delivery → 6. Production Support
